Bidirectional Operation Cranked Music Box Mechanism

Special Crankshaft Music Box Musical Mechanism

  • 1) Model Code: MHS18BD, Bidirectional Operation Hand Crank Music Box

    2) Basic Function: Mechanical musical device

    3) Characteristic Function: Both ways operated, and Crankshaft on top

    4) Level: Standard 18 note

    5) Operating Principle: Crank operated metallic Drum knocking the steel Comb

    6) Main Structure: Alloy base, Alloy drum, Metallic crank, Steel Comb

    7) Dimensions: 47x45x21mm(Not including the length of crank)

    8) Color: Silvery

    9) Play Power: Crank operated

    10) Tunes Resource: Richest standard 18 note pattern tunes resource, More than 800 most popular songs for selection

    11) Tunes Custom: Accept to customize your own songs

    12) Music Notes Hold: 8~16 Bars, About 70 notes

    13)Music Length: 12 ~ 20 seconds

    14) Service Life: More than 5000 times

    15) Safety: EUR&US Standard, EN71(Part1~3), RoHS, REACH

    16) FOB Unit Price, 1.49~2.49usd

    17) MOQ: 400pcs per song

inquiry
  • Description
    • Model Code: HS18BD, BIDIRECTIONAL HAND CRANK MUSIC BOX

      1) Basic Function: Mechanical sound device playing music

      2)Operation: Crank Operated

      3)Characteristic:

      - Anticlockwise or Clockwise operation, two directions are available

      4)Music Length: 12 ~ 20 seconds

      5)Working Life (Cycle): More than 5000 times

      FeMelody Support,

      - Support the richest tunes resource, especially the Children music

      - Support Mini order, FOB price,2.25~4.45USD

      - Very cost-effective if more than MOQ

      - High quality musical movement, soft clear sound style, stable quality more than 5000 times

  • Detailed introduction
    • 1. The most popular hand crank music box

      The 18 note hand crank music box is one of most popular styles in the world. It may be as kids music box toys, also can be installed various boxes and become wooden hand crank music box, paper hand crank music boxes, Polyresin hand crank music boxes or others. It’s a hand operated music box products, it’s very fun and helpful to Child’s body and brain when children playing

      2. The cheapest hand crank music box toys style

      The model has the simplest structure, without spring power device, without additional functions, playing by hand, And share the core part-Comb and Drum with other style of standard 18 note music boxes, so the cost is the cheapest one in all music boxes.

      3. Simplest structure, Most Stable quality, Lower rejects

      Simple mean Stable. This standard 18 note hand crank music box has the simplest structure, and share FM top quality core parts, has very stable quality, lowest defective rate.

      4. Share the richest 18 note pattern tunes Resource, you want you get.

      Total 3000 tunes,  and more than 100 hot baby lullaby tunes for selection. Still can not find the one you love?  ok, customize songs for you. How to customize? Refer to the Tune Custom Guide.

      5. Support Smaller order.

      The mini order quantity is 400pcs per tune. No problem to offer smaller order but the cost will rise, And certainly the cost can be lower if larger order quantity.

      6. Why FeMelody hand crank music boxes be in great quality

      1) FeMelody Equipment, Produced by unique equipment in the world, the MUSICAL MOVEMENTS AUTOMATIC ASSEMBLY LINE, Make sure the best product consistency, And Powerful producing capacity, Make sure Timely delivery.

      2) FeMelody Comb

      Comb is the most important core in crank operated music box, all melodies come from this part. We use unique formula steel material and proprietary manufacturing process to make sure all notes are in perfect intonation and sound beautiful and clear

      3) FeMelody Drum

      Drum is the accessory which knocking the keys of comb and making sound. It’s also a important part in hand crank music box. We take more than 15 processes to make sure every pins are in same height and knocking evenly the keys of comb.

      In addition, we make reasonable arrangement of notes,make sure all notes are in right Rhythm   and and the reasonable arrangement also can raise the service life of comb and drum

      4) FeMelody Crankshaft

      We can make sure the perfect straightness, it’s very important to make the hand crank music box operating smoothly.

      In addition, we design double thread to get more efficiency for driving

      7. How to identify the High quality hand crank music and Low quality hand crank music

      1) Certainly, first of all, listen it. The sound should be clear, in right intonation, in right rhythm and low noise.

      2) The appearance should be clear, no dirty. The metallic part should be fresh color, not look black and old.

      3) Complete manufacturing processes. Almost low quality music box parts lost the the Tight alignment process which make the notes be in exact intonation. The tight alignment process require special equipment and technology, most of factories producing low quality music box can not do that.


  • FeMELODY
    • FeMELODY TUNES

      FeMelody Have rich tunes resource, more than 800 hot tunes of 18 note pattern for selection, also can accept to customize your own songs.Refer to the Tunes custom guide)

      FeMELODY WATRRNTY

      A)Six months for common music box movements, 12 months for Luxury music box movement.

      B)For regular customers, once the quality problem is confirmed,the free replacements for defects coming with next order together

      C)For others, offer 0.2% extra in advance. Also can offer free replacements if quality problem is confirmed, but customer need to pay delivery cost

      FeMELODY WARM TIPS

      1)Our company reserves the right to update the products without prior notice, so please confirm with us before you place an order.

      2) Some tunes are not the public songs, Buyer and Importer should deal with it according to their locate rules. Information on how to locate copyright holders can be obtained from us
